Description
Support System Lower Frame (In) Acrylic Colour Hatch Weight (Lb) Acrylic Window Thickness (In) Self Supporting 9/16 Smoke Grey 10.1 5/16 Dimensions Length X (In) Width Y (In) Height Z (In) Radii R (In) Cut-Out Length X1 (In) Cut-Out Width Y1 (In) Cut-Out Radii R1 (In) 19 5/16 19 5/16 1 2 7/8 16 9/16 16 9/16 1 11/16 Mounting Instructions Fit To A Flat Surface With A Maximum Tolerance Of +/- 1Mm. Fastening Size At Hinge Section Use M6 (1/4&Quot;). Fastening Size For Lower Frame Use 5Mm Csk Screw No.10 Unc 2 Ba.
